Dimmer & Motion Sensor Switch integrates light control, motion detection, illuminance detection together into one device. It triggers light ON/OFF by detecting motion and illuminance, so it may realize light ON when people coming, light ON when getting dark and many other smart control scenes.
Multiple ways of lighting adjustment
Automatically switch on and off by human motion detection
Precise brightness control by percentage
| General | |
| Model Number | LS174 / LS154 (Japan) |
| Product Type | Wall mount switch |
| Wiring | Live+neutral |
| Control Unit | The triac control unit(one way) |
| Compatible Lights | Filament, halogen, LED lamp or other lamps with Triac control |
| Operating Temperature | -5~45°C |
| Operating Humidity | 5~90% |
| Power Supply | AC 100-240V 50/60Hz |
| Static Consumption | <1W |
| Maximum Overload | Resistive load: 250W Inductive/Capacitive load: 200W |
| Button | Dimmer button(Pressable), pairing&matching button, safety button |
| Indicator | Dimmer indicator light |
| Motion Detection | Yes (embedded motion sensor) |
| Light Detection | Yes (embedded light sensor) |
| Radio | |
| Radio Protocol | CoSS |
| Signal Range(Open Field) | 100m |
| Construction | |
| Color | Ivory white |
| Dimension | 120*70*47mm (with dimmer button), 68*40*27mm (flush-mount) |
| Weight | 110g |
| Casing | Bottom cover: PC, others: ABS+PC |
