This product adopts advanced optical sensing principle, can quickly find the smoke during the initial smoldering of the fire, find the occurrence of fire as soon as possible and send wireless signals to the gateway through independent sound alarm and wireless signal to timely remind users to alarm, extinguish fire or escape, reduce or avoid losses.
This product adopts advanced optical sensing principle, can quickly find the smoke during the initial smoldering of the fire, find the occurrence of fire as soon as possible and send wireless signals to the gateway through independent sound alarm and wireless signal to timely remind users to alarm, extinguish fire or escape, reduce or avoid losses.
Stable and sensitive photoelectric sensor
Rich product certification: CCCF/CE/FCC
High decibel alarm volume
3 years long battery life
| General | |
| Model Number | MIR-SM100 |
| Operating Temperature | -10~55℃ |
| Operating Humidity | 5~90% |
| Detection | 5m/120° |
| Power Supply | 1 Battery CR123, 3V |
| Power | Transmit power≤ 10dBm Standby current≤ 15uA |
| Battery Life | Up to 3 year |
| Alarm volume | ≥ 85dB (3 meters in front) |
| Installation method | Ceiling Mount, Wall Mount |
| Radio | |
| Radio Protocol | ZigBee |
| Signal Range(Open Field) | 100m |
| Construction | |
| Color | Ivory white |
| Dimensions | Φ90x37.5mm |
| Weight | 106g |
| Casing | ABS |
